JHRXLK-300 SF6 Infrared Gas Leak Detection Temperature Imager
Using refrigerated infrared detectors, it is possible to detect the leakage of sulfur hexafluoride very quickly, safely and accurately
High-definition, high-sensitivity pseudo-color image to display the infrared thermal spectrum of an object
Ideal for detecting SF6 gas or chemical leaks in large work areas
Imaging performance and optical parameters | parameter |
focal plane array | Cooling type infrared detector |
wavelength range | 10.3 ≤ 10.7μm |
Measure | |
precision | ± 1 ° C of the temperature range (0-100 ° C) or ± 2% of the temperature range reading (> + 100 ° C) |
Temperature measurement range | -40℃～+50℃；+0℃～+250℃；+200℃～500℃ |
Temperature measurement method | Manual/automatic, can set the temperature measurement point, area (the highest temperature and the lowest temperature can be set in the area), isotherm, temperature difference, with sound alarm and color alarm, and automatically track the highest/lowest temperature point in real time |
measurement analysis | |
point temperature measurement | 10, including maximum/minimum/average |
regional temperature measurement | 5, including maximum/minimum/average |
Line temperature measurement | 5, including maximum/minimum/average |
Circular area temperature measurement | 3, including maximum/minimum/average |
